CASE STUDIES &
TECHNICAL DELIVERABLES

Optical 3D ScannerSolidWorksCMM Verification

Reciprocating Compressor Housing – Multi-View Reconstruction

Full 360° digitization and parametric CAD rebuild of a reciprocating compressor housing, capturing complex internal valve port geometry and cylinder bore alignments.

±0.02 mm

Bore Concentricity

Case #5

Machine Housing – Heavy Equipment CAD Reconstruction

Scan-to-CAD VerifiedMicron Precision

Machine Housing – Heavy Equipment CAD Reconstruction

Reverse engineered a heavy-tonnage machine housing from raw scan data, validating bearing bore concentricity and load-bearing mounting interfaces.

Micron Precision

Bearing Alignment

Case #6

Metrology Laser CMMPTC Creo / SolidWorksFEA Validation

Scan-to-CAD VerifiedISO Class 6

Timing Gear – Precision Tooth Profile Recovery

Full digitization and parametric reconstruction of a precision timing gear, recovering involute tooth profiles, keyway geometry, and hub concentricity.

ISO Class 6

Gear Tooth Accuracy

Case #7

Optical 3D ScannerGeomagic Design XSolidWorks

Wire Drawing Housing – Industrial Equipment Digitization

Scan-to-CAD Verified±0.025 mm

Wire Drawing Housing – Industrial Equipment Digitization

Precision scan and CAD reconstruction of a wire drawing machine housing, capturing complex internal passage geometry and mounting interfaces.

±0.025 mm

Bore Alignment

Case #8

Structured Light ScannerSolidWorksCMM Verification

Bearing Housing – Precision Bore Alignment Recovery

Scan-to-CAD Verified±0.015 mm

Bearing Housing – Precision Bore Alignment Recovery

Micron-accurate digitization of a heavy-duty bearing housing, restoring precision bore alignments, seal grooves, and lubrication port geometry.

±0.015 mm

Bore Runout

Case #9

Optical 3D ScannerSolidWorksGD&T Documentation

Rod Drawing Housing – Manufacturing Data Recovery

Optical 3D ScannerSolid EdgeCMM Verification

Rod Drawing Housing – Manufacturing Data Recovery

Complete reverse engineering of a rod drawing machine housing, capturing multi-axis bore alignments and complex external mounting interfaces.

±0.02 mm

Multi-Axis Alignment

Case #10

Racket Die – Male & Female Cavity Reconstruction

Die & Mould

Scan-to-CAD Verified100% CAD

Racket Die – Male & Female Cavity Reconstruction

Complete reverse engineering of male and female racket die cavities, restoring precision parting line geometry and complex compound-curve surfaces.

100% CAD

Cavity Match Verified

Case #11

Optical ScanGeomagic Design XCNC CAM Toolpath

Plastic Cup Die – Thermoform Cavity Digitization

Die & Mould

Scan-to-CAD Verified±0.03 mm

Plastic Cup Die – Thermoform Cavity Digitization

Precision scanning and CAD reconstruction of a thermoform plastic cup die cavity, recovering wall draft angles and cooling channel geometry.

±0.03 mm

Surface Accuracy

Case #12

Structured Light ScannerSolidWorksCNC EDM Toolpath

Plastic Container Die – Male & Female Set Reconstruction

Die & Mould

Optical 3D ScannerSolid EdgeMould Flow Analysis

Plastic Container Die – Male & Female Set Reconstruction

Full reverse engineering of a plastic container injection mould die set, capturing complex undercut geometry, ejector pin locations, and cooling circuits.

±0.02 mm

Cavity Precision

Case #13

Scan-to-CAD Verified100% Surface

Italian Wall Hung – Ceramic Sanitaryware Digitization

High-resolution optical scanning and surface reconstruction of an Italian wall hung ceramic sanitaryware unit for mould pattern development.

100% Surface

Form Captured

Case #14

Optical 3D ScannerGeomagic FreeformMould CAD

Orissa Pan – Traditional Sanitaryware CAD Modeling

Scan-to-CAD Verified±0.5 mm

Orissa Pan – Traditional Sanitaryware CAD Modeling

Precision digitization of a traditional Orissa pan ceramic design for modern mould tooling development, preserving original form language.

±0.5 mm

Post-Fire Accuracy

Case #15

Optical 3D ScannerSolidWorksMould Design CAD

Water Tank – Ceramic Storage Vessel Digitization

Scan-to-CAD Verified100% Geometry

Water Tank – Ceramic Storage Vessel Digitization

Full-form digitization of a ceramic water tank and lid assembly, enabling precision mould tooling development for mass production.

100% Geometry

Complete Capture

Case #16

Optical 3D ScannerGeomagic Design XMould Flow Analysis

Wash Basin – Premium Sanitaryware Surface Modeling

Scan-to-CAD VerifiedClass A Surface

Wash Basin – Premium Sanitaryware Surface Modeling

High-fidelity surface capture and CAD modeling of a premium wash basin design for automated mould production tooling.

Class A Surface

Surface Quality

Case #17

Optical 3D ScannerGeomagic FreeformNURBS Surface Modeling

Plastic Container – Injection Mould CAD Development

Plastics
